Description
Color: Gasket: Black
Dimensions W (mm): 150
Dimensions D (mm): 150
Dimensions H (mm): 90
Material: Mounting Base Screw: Iron
Specification: Nut: None
Type: G Type
Temperature Range (Celsius degrees): -10 to 60
Dimensions A (mm): 120 (Bottom Mounting Hole)
Surface Treatment: Latch: Untreated, Mounting Base Screw: Trivalent Chromate
Protection Level: IP65
Dimensions C (mm): 120 (Bottom Mounting Hole)
Material (Cover): ABS Resin
Flame Resistance: UL94HB
Material (Gasket): Polyurethane
Material (Body): ABS Resin
Color (Cover): White Gray
Corresponding Body Color: White Gray
RoHS Directive (10 Substances Compliance): Compliance
Characteristics: Waterproof Dustproof Open-Close
Weight (g): 343
Effective Dimensions (Width) (mm): 125.7 (Internal)
Effective Dimensions (Depth) (mm): 125.7 (Internal)
Effective Dimensions (Height) (mm): 75.5 (Internal)
Material (Latch): Stainless Steel
