Description
Color: Gasket: Black
Dimensions W (mm): 135
Dimensions D (mm): 185
Dimensions H (mm): 85.5
Material: Mounting Base Screw: Iron
Specification: Nut: None
Type: T Type
Operating Temperature Range (Celsius degrees): -10 to 60
Dimensions A (mm): 95 (Bottom Mounting Hole)
Surface Treatment: Latch: Unprocessed, Mounting Base Screw: Trivalent Chromate
Protection Level: IP65
Dimensions c (mm): 145 (Bottom Mounting Hole)
Material (Cover): Polycarbonate
Flame Retardancy: UL94HB
Material (Gasket): Polyurethane
Material (Body): ABS Resin
Color (Cover): Transparent
Compatible Body Color: White Gray
RoHS Directive (10 Substances Compliance): Compliant
Characteristics: Waterproof Dustproof Open-Close
Weight (g): 410
Effective Dimensions (Width) (mm): 110.4 (Internal)
Effective Dimensions (Depth) (mm): 160.4 (Internal)
Effective Dimensions (Height) (mm): 72.2 (Internal)
Material (Latch): Stainless Steel
