Description
Pressing Force (kN[kg]): 1.6[160]
Handle Operating Angle (degrees): 45
Accessories: Nut M10 P=1.5
Stroke (mm): 12
Material (Main Body): SS400 (Zinc Plated)
Weight (g): 454
Type: Side-Pressing
Maximum Height (mm): 123.3
Material (Handle): PVC
Base: Flange
Maximum Length (mm): 220.24
